Electric-hydraulic truck tire changer 14" to 26"
Item No.: 159
Electro-hydraulic tyre changer. Particulary suitable for operating truck and bus wheels. Tubeless or tyres with ring from 14" to 26".
Description
Details
Instruction
Electro-hydraulic tyre changer. Particulary suitable for operating truck and bus wheels. Tubeless or tyres with ring from 14" to 26".
Specification
Application range: Truck/Bus/Tractor/Industry vehicle
Length: 1580mm (62 Inch)
Width: 1900/2060mm (75/21 Inch)
Height: 760/1090 (30/43 Inch)
Weight: 535kg
Clamp range: 14-26 Inch
Tyre diam. / width: 1500mm/780mm (59/31 Inch)
Drive power: 1.5kw
Cycle time: 7.34 RPM
Outside Dimension: 2080mm*1680mm*950mm
Drive moment: 4250Nm
Work pressure: 130bar
Min. Diam. of spoke: 150mm (6 Inch)
Max. Distance of track: 1214 (48 Inch)
Power supply: 380V/ three phase 50Hz, 220V single phase
Operation Voltage: 24V
Pump power: 1.5kw
Gross Weight: 640kg
Diagram
Packing size
Package
Warranty: 12 months
Lead time: One week
Electro-hydraulic tyre changer. Particulary suitable for operating truck and bus wheels. Tubeless or tyres with ring from 14" to 26".
Specification
Application range: Truck/Bus/Tractor/Industry vehicle
Length: 1580mm (62 Inch)
Width: 1900/2060mm (75/21 Inch)
Height: 760/1090 (30/43 Inch)
Weight: 535kg
Clamp range: 14-26 Inch
Tyre diam. / width: 1500mm/780mm (59/31 Inch)
Drive power: 1.5kw
Cycle time: 7.34 RPM
Outside Dimension: 2080mm*1680mm*950mm
Drive moment: 4250Nm
Work pressure: 130bar
Min. Diam. of spoke: 150mm (6 Inch)
Max. Distance of track: 1214 (48 Inch)
Power supply: 380V/ three phase 50Hz, 220V single phase
Operation Voltage: 24V
Pump power: 1.5kw
Gross Weight: 640kg
Diagram
Packing size
Package
Warranty: 12 months
Lead time: One week
