CX5-280 Low Rise scissor lift

Item No.: 091


1. Min. height 100mm,no need dig foundation
2. Small volume design, suitable for tire changing and repairing Light weight and movable
3. Safety lock configuration, easy to control, safe and reliable

Lifting Capacity 6171Lbs/2800kg
Lifting Height 24"/620mm
Lifting Time 25seconds
Min Height 4"/100mm
Overall Length 81"/2045mm
Platform Width 18"/460mm
Overall Width 73"/1860mm
Platform Length 53"/1345mm
Motor Voltage 220V/380V
Frequency 50Hz or 60Hz
Phase 1Ph/3Ph
Net Weight 829Lbs/376kg

Produtct Details

Warranty: 12 months

Lead time: One week
